Engineered for hazardous areas where flammable gases, vapors, or dust may be present.
Die-cast aviation-grade aluminum housing + explosion-proof tempered glass for robust impact and long-term clarity.
Stable output at 100–130 lm/W with SMD3030 LEDs and Meanwell/Sosen drivers.
IP66 ingress protection and WF2 anti-corrosion rating for harsh, saline, or chemical atmospheres.
Flexible mounting: wall, ground, or ceiling with a 180° adjustable bracket.
| Quantity: | |
|---|---|
BS-FB1
Bestshow
BS-FB1 is built for the moments that must not fail—when a pump kicks on, when solvent vapors linger after cleaning, when a dust cloud hangs above the line. The housing feels dense and cool to the touch; the tempered glass lens sits flush and sealed, keeping out spray and grit. Once powered, the beam lays down even, high-contrast light that helps crews read gauges, spot leaks, and move with confidence.
Behind the simplicity is a conservative electrical design: SMD3030 emitters run at comfortable drive currents; Meanwell or Sosen drivers manage thermal and surge events; the power factor stays honest at 0.9. Operators notice fewer re-lamping events, supervisors notice steadier uptime, and finance notices maintenance lines that finally flatten.
| Item | Specification |
|---|---|
| Model | BS-FB1 |
| Wattage Options | 50 / 100 / 150 / 200 / 250 / 300 / 400 W |
| Luminous Efficacy | 100–130 lm/W |
| CCT | 3000K / 4000K / 6500K（extended 2700–7000K range） |
| LED Source | SMD3030（Epistar / Sanan） |
| Power Factor | 0.9 |
| Input Voltage | AC90–290V |
| Ingress Protection | IP66 |
| Anti-corrosion | WF2 |
| Material | Aviation-grade aluminum + explosion-proof tempered glass |
| Driver | Meanwell / Sosen（SCP/OVP protection） |
| Mounting | Wall / Ground / Ceiling；180° adjustable bracket |
| Certifications | ATEX、CE、RoHS、CCC |
| Warranty | 3–5 years |
Hazard-ready build: explosion-proof glass + aviation aluminum form a rigid, sealed envelope that resists impact, spray, and fines.
Stable efficacy: 100–130 lm/W ensures dependable lumen output without pushing components to the edge.
Driver integrity: Meanwell/Sosen options with short-circuit and over-voltage protection guard against transient faults.
Outdoor-proofing: IP66 + WF2 anti-corrosion support long service in coastal yards, refineries, and chemical loading bays.
Installation agility: wall/ground/ceiling hardware with 180° adjustable yoke simplifies aiming and uniformity.
OEM/ODM: branding, harness length, and bracketry can be customized to your standard kit.
What your HSE team wants to see—organized for review.
Explosion environments: Designed for hazardous locations where gases, vapors, or dust are present (application suitability assessed by the AHJ at the site level).
Protection envelope: IP66 ingress protection; explosion-proof tempered glass; WF2 anti-corrosion rating.
Certifications: ATEX / CE / RoHS / CCC as standard for this model.
Documentation package: datasheet and installation guidance available; IES files provided on request for lighting plans.
Governance note: final classification and mounting method should align with local codes and site safety procedures.
Output plan: 50/100/150/200/250/300/400W selections to match ceiling height and task needs.
Efficacy window: 100–130 lm/W tuned for longevity vs. peak drive.
Color strategy: 3000K/4000K/6500K (extended 2700–7000K range) to balance visual acuity and worker comfort.
Visual comfort: clear, tempered lens maintains beam fidelity in dusty or humid spaces.
Input voltage: AC90–290V (PF 0.9) for global deployment and generator compatibility.
LED engine: SMD3030 from established chipmakers (Epistar/Sanan).
Driver: Meanwell or Sosen, with short-circuit/over-voltage protection to withstand utility spikes and motor starts.
Optional dimming / controls: 0–10V or on-off control can be specified for energy policy alignment (contact us for SKUs).
Housing: aviation-grade aluminum, dense and thermally efficient; finish resists abrasion and salt spray.
Lens: explosion-proof tempered glass—hard, clear, and easy to wipe clean after solvent fog or sea mist.
Mounting: wall, ground, ceiling; 180° adjustable bracket for quick aiming during commissioning.
Serviceability: straightforward access to terminals; standardized fasteners for glove-on maintenance.
Oil & Gas / Petrochem: process areas, pump rooms, loading racks—stable light through vapor events.
Metals / Mining: mill floors with airborne fines; bright, uniform light supports inspection.
Marine / Shipyards: cranes, decks, and yards with salt spray; enclosure finish resists corrosion.
Manufacturing / Warehousing: aisles and mezzanines where dust and forklift exhaust accumulate.
Fueling & Maintenance Bays: robust lens resists solvent haze and impacts from hand tools.
Operational reliability：conservative thermal/electrical design reduces downtime and unscheduled lifts.
Total Cost of Ownership：balanced efficacy and driver protection extend service intervals—fewer site visits, fewer permits.
OEM/ODM program：branding, harnessing, brackets, and carton artwork customized for your network.
Delivery assurance：sample in 3–5 days，mass-production 1–2 weeks to keep projects on schedule.
Pre-shipment aging：full burn-in to screen early-life failures before arrival.
Q1: Is the fixture suitable for wash-down or outdoor yards?
Yes—IP66 keeps out high-pressure spray and airborne dust. The WF2 anti-corrosion rating supports coastal and chemical-adjacent use.
Q2: What driver options are available?
Meanwell or Sosen. Both provide short-circuit/over-voltage protection to safeguard against motor starts and grid fluctuations.
Q3: Can I align the light with existing control policies?
We can provide on-off or 0–10V dimming options on request, allowing alignment with site energy standards.
Q4: What’s the lead time?
Typical: samples 3–5 days; mass production 1–2 weeks depending on quantity and customization.
Q5: Do you support lighting plans and IES files?
Yes—submit layout info (area, mounting height, target lux). We’ll return an IES-based lighting plan for count validation and aiming.
Q6: What about temperature limits or classification labels?
Final suitability depends on your local code/AHJ and application details. Provide your target classification and ambient range; we’ll align the documentation and configuration.
